Remote Control Die Transfer Cart For 20 Tons Steel Billet Material Handling

Product Categories

Henan Remarkable Intelligent Technology Co., Ltd.

Contact Now

Remote Control Die Transfer Cart For 20 Tons Steel Billet Material Handling

Name: Remote Control Die Transfer Cart For 20 Tons Steel Billet Material Handling
Brand: Remarkable
Price: 1 USD

Quality Remote Control Die Transfer Cart For 20 Tons Steel Billet Material Handling for sale

Brand Name : Remarkable

Model Number : RWP-20T

Certification : CE, ISO9001

Place of Origin : China

MOQ : 1 set

Price : Negotiable

Payment Terms : T/T, D/A, D/P, L/C, Western Union, MoneyGram

Supply Ability : 300 sets per year

Delivery Time : 30-45 days

Packaging Details : The whole cart will be packed by the tarp, the parts will be packed by polywood case.

After-sales service provided : commissioning and training

Color : Customized

Application : Industry metallurgy, Material handling/steel coil/industrial

Capacity : 20 tons

Power supply : Battery

Load capacity : customized

Running speed : 0-20m/min

Power source : battery

Usage : material transferring

Safety features : Warning alarm and End stop, end stop, Warning alarm

Control model : wireless remote and hand pendant

Contact Now

Remote Control Die Transfer Cart For 20 Tons Steel Billet Material Handling

^{1. The Stop Device Can Effectively Protect The Personal Safety Of The Staff}

^{2. The Limit Limit Device Can Effectively Prevent The End Derailment Of The Electric Flat Car}

^{3. The Sound And Light Alarm Device Can Remind The On-Site Personnel To Pay Attention To Safety}

^{4. The Anti-Collision Buffer Device Can Help Buffer In Case Of Emergency And Effectively Avoid The Damage Of The Car Body}

^{5. The Emergency Stop Button In Case Of Emergency, The Emergency Stop Button Can Help The Flat Car To Stop}

^{It Can Be Equipped With Handle And Remote Control. The Wire Length Of The Handle Is Generally 3m Or 5m, And There Are Four Keys And A Rocker On The Handle. The Four Keys Are: Start, Emergency Stop, Forward And Backward. The Rocker Controls The Steering Of The Flat Car. The Rocker Moves Left, The Flat Car Turns Left, The Rocker Moves Right, And The Flat Car Turns Right (The Direction Of The Motor Is The Forward Direction). If You Want To Stop The Car, You Can Release The Forward Or Backward Button Or Press Stop Button, If You Want To Start Again, Turn The Emergency Stop Clockwise And Press Start. The Remote Control Is Six Key Control, Including Start, Stop, Forward, Backward, Left Turn And Right Turn. When Turning Left Or Right, The Corresponding Direction Key Must Be Pressed At The Same Time. When Starting Again, Press The Start Button Directly. The Handle And Remote Control Can Not Control The Flat Car At The Same Time (The Control Box Has The Handle And Remote Control Switch). The Flat Car Is Equipped With Handle Placing Box, Which Is Convenient For Handle And Remote Control.}

Remote Control Die Transfer Cart For 20 Tons Steel Billet Material Handling

Technical parameters for trackless electric transfer carts
rated load(t)	5	10	15	20	30	40	50
impacted rated load(t)	7.5	15	22.5	30	45	60	75
structure of frame	steel plates welded, beam structure
max. wheel load(t)	2.8	4.3	4.8	5.6	7.7	10	12
ground requirement	cement floor					steel plate ground
ground requirement	cement floor					steel plate ground
table size(mm)	3000×2000	3600×2000	4000×2200	4500×2200	5000×2200	5500×2300	6000×2300
height of the whole cart(mm)	450	530	600	600	650	700	700
ground clearance(mm)	50
wheels base(mm)	1500		1700			1800
axles distance(mm)	2500	3100	3400	3900	4300	4800	5200
turning radius(mm)	2501	3101	3401	3901	4301	4801	5201
turning type	turning while driving with no stop
control method for turning	control button
turning structure	mechanical
motor power(Kw)	3.5	5	6	7	10	12	15
wheel diameter(mm)	300 x 4	350 x 4		400 x 4	400 x 6	500 x 6
wheel material	ZG55+hydropur ture
running speed(m/min)	0-20
brake principle	electric magnetic brake
operation method	with wire or no wire
battery maintenance	free of maintenance
charger's installation	installed on cart				split-type
radar control	3-0.3m, automatic stop for obstacles
warning equipment	sound and light
other functions	turning light, night light and power display

Remote Control Die Transfer Cart For 20 Tons Steel Billet Material Handling
